Structural Modelling

SteelTech provides 3D structural (Steel, Concrete & Precast) modeling for global and domestic Structural Engineers, Builders, Developers and Contractors addressing practical situation during inception, design, construction and operations

SteelTech’s Structural 3Dmodeling Services include: (CAD to BIM conversion)
  • 3D Structural Modelling with finishes
    • Existing condition modeling from CAD, pdf or scanned drawings
    • DD, CD drawing production from BIM
    • BIM Analytics and BIM-based visualization support
  • 3D Analysis Model Development, Load generation
  • 3D Structural Steel Model with Connection for
    • General Arrangement Drawings (GAD), Erection Drawing
    • Structural BOQ
  • Mock-Up / Proto type modeling

SteelTech’s experience team of 3D modellers, checkers have created models for residential towers, mixed-use projects, commercial buildings, shopping centers, hospitals, airports, hotel complexes, transport infrastructure, water and waste water treatment plants and distribution systems. We have worked with leading companies in US, Canada, UK, Australia and India.

The process of 3D Structural modeling offers various benefits including time savings in the design phase. Creation of Structural models allows in design time, at the same time retaining fine details of the final architecture plan. Structural modeling enables architects to visualize the building in physical space and predict clashes. The clash detection and resolution activity is carried out again during construction stage so as to finalize the model and producing coordinated MEPFF drawings.Our team has expertise in using Revit Structure, Tekla Structure, ArchiCAD, Google Sketchup and we chose the BIM tool based on type of job and most supporting BIM software for specific job. SteelTech also delivers Revit 3D Models from 3D laser scan data in the form of ‘point cloud’ data.

<
